Stamping Right Side Panel Of Through-Wall ATM Cash Withdrawal Module

Cash Withdrawal Module

  • Material: SECC Steel
  • Process: Metal Stamping And Mold Making
  • Stamping Size: Custom Size
  • Stamping Type: Metal Forming
  • Stamping Mold: Compound Mold
  • Tolerance: Custom
  • Fine Blanking Method: Multi-Station
  • Surface Treatment: Custom
Machinery | Steel

High-Quality Stamping Right Side Panel Of Through-Wall ATM Cash Withdrawal Module

The metal stamping part of the electrolytic plate shown is a precision part of the right side plate designed by for the cash withdrawal module of the through-wall ATM. This case mainly shows the parameters, process and some common problems of the part from various aspects. is committed to providing R&D and customized production solutions for high-end precision stamping parts and their structural modules.This part has the following features:

  • Durability, the coating on the surface of the product has excellent electrochemical protection performance, the coating is thick and dense, has strong bonding force with the steel substrate, and has good durability, and the service life can be maintained for more than 20 years;
  • The difficulty is high, the part has many special-shaped holes, and its dimensional error should be guaranteed to be ≤0.1mm, which has high production difficulty and mold technical requirements;
  • Safety, it is made of metal material with a thickness of 2mm, and multiple screws are installed for fastening, and the safety performance is evident;
  • Iterative, customized mass production, version upgrade and update can be flexibly dealt with, reducing cost input;

Note: There are more detailed photos of products at the bottom of the page to show the product features of electrolytic plate metal stamping parts.

The Parameters Of Stamping Through-Wall ATM Cash Withdrawal Module Right Side Panel

Product Size236*206*35mmExpand Size325*275*2mm
Product MaterialSECCMaterial Thickness2.0mm
Product Weight333.5gMold TypeSingle die & compound die, 4 sets in total
Surface TreatmentnoneProcessing Difficultycomplex
Size Tolerance±0.1mmAngle Tolerance±0.3°
Stamping Right Side Panel Of Through-Wall ATM Cash Withdrawal Module

The Production Process Of Stamping Through-Wall ATM Cash Withdrawal Module Right Side Panel

Serial NumberProcessPunch TonnageProcess Description And Precautions
1Composite Blanking160 TThe shape and prototype hole of the product are punched out at one time, and at the same time, the size requirements of the product and the burr height requirements of the product can be guaranteed;
2Shape And Hole, Convex Meter160TThere are two processes in this trip, which are punching the complex hole again and punching the convex meter at the fixed point;
3Hit The Front, Convex Rice110TRemove peripheral burrs and use convex meters to locate special positions to prepare for subsequent processing ;
4L Song110TStamping, bending and die bending can greatly ensure product size requirements and production process stability ;
5TeethAuxiliary processTapping the special holes, pay attention to the deviation of the size of the holes;
6WeldingAuxiliary processWelding the assembled parts (see the picture below for details) ;
7DegreasingAuxiliary processRemove surface oil stains by surface ion cleaning machine ;
8Socket NailAuxiliary processThe pressure riveting process allows the parts to be closely combined with the nut (rivet) to meet the customer’s assembly requirements ;
9Silver OilAuxiliary processSecondary coating on surrounding areas that are prone to rust ;
10Quality InspectionAuxiliary processComprehensively check the dimensional error of electrolytic plate metal stamping parts and whether the appearance requirements after surface treatment are qualified;
11PackageAuxiliary processPackaging engineers design exclusive packaging solutions to ensure the quality of products in the follow-up operation process and avoid losses;

Why Choose Our Stamping Through-Wall ATM Cash Withdrawal Module Right Side Panel Service?

  • Are Cost-Efficient
  • Manufacture Parts That Are Precision-Built
  • Expert-Level Consultation and Design Assistance
  • Provide Free Tool & Die Insert Storage and Maintenance
  • Offer Complete In-House Tool & Die Capabilities
  • BE-CU And His Core Supplier Sipx has large to small precision stamping presses. Our presses range from 40 to 700 tons, with bed sizes up to 150 inches and speeds up to 400 strokes per minute.
  • Specializing in automated precision progressive dies, our feed capability ranges from 0.008 to 0.375 inch thick material with coil widths up to 50 inches and weights to 15,000 pounds.

Advanced Equipment to Create a Diverse Range of Designs,Sizes, and Thicknesses Large or Small Parts Can Be:

  • – Pierced
  • – Formed
  • – Drawn
  • – Extruded
  • – Marked
  • – And More!

Expert-Level Consultation and Design Assistance including:

  • Engineering drawing analysis
  • Design feasibility reviews
  • Functionality assessments
  • Confirmation of supply tolerances, cost ratios, and other important project considerations
  • Informed recommendations about when to use stamping versus other technologies

Contact Be Cu Now for your Custom Metal Stamping, We are your best online Stamping services choice!

Specifications of Stamping Through-Wall ATM Cash Withdrawal Module Right Side Panel

Raw Material Thickness0.040″ to 0.375″
MaterialStainless Steel (304, 305, 316, 430 & 434), Aluminum (3003, 5052, 6061), Cold Rolled Steel (1008, 1010), High Carbon Steel (1035), Nickel and Pre-plated Steel, Galvannealed Steel, Brass (80-20, 80-15, 70-30), Copper, HSLA.
Presses Ranging40 to 700 tons
Stamping ProcessFlanging, punching, bending, necking, trimming, deep drawing, cold extrusion, precision blanking, bulging
Quality ControlMaterial Analysis、Hardness Testing、Mechanical Testing、Magnetic Particle Inspection、X Ray Testing、Leakage Testing、Ultrasonic Inspection
Surface TreatmentPowder coating,Nickel plating,Anodic oxidation,Chrome plating,Yellow zinc plated,Electroless nickel plating,Chemical conversion coating,Zinc plating,Electroplating,etc
Customized Drawings2D:DWG,DXF,PDF & 3D:ASM,IGS,STEP,STP .ETC

The Common Problems Of Stamping Through-Wall ATM Cash Withdrawal Module Right Side Panel

1.How to enhance the quality assurance of electrolytic plate metal stamping parts?

Answer: There are two aspects that can be improved, and the effect is significant:

One is hard power, such as the introduction of production equipment. The output quality of punch presses with newer and more advanced models is much higher than that of old machines, especially when the degree of automation is getting higher and higher. better;

The second is soft power. An independent quality department is established, and a strong production team is equipped with a high-quality quality supervision team to grasp the quality status in real time and solve problems in a timely manner.

Be-cu Company has been actively promoting foreign advanced equipment and cultivating high-end technical talents for many years, laying a solid foundation, aiming to contribute more strength and scientific research and technical support in promoting the upgrading of China’s precision and intelligent manufacturing!

2. Any suggestions for the selection of metal stamping parts suppliers?

A: The selection of supplier regions is particularly important, which not only saves transportation costs, but also facilitates subsequent demand docking. Generally speaking, medium and large-scale manufacturers will have production sites in multiple regions. For example, has three branches in Shenzhen, Jiangmen and Tianjin. At this time, they can choose the closest company according to the principle of proximity.

3. Roughly talk about the application field of electrolytic plate punching parts

Answer: Because the electrolytic plate has good anti-oxidation effect, high hardness and beautiful appearance, there are many suitable application scenarios. Here are two: communication terminals, automobile stamping parts, communication terminals have higher requirements on precision. Signal transmission performance, high-frequency signal transmission requires good electrical conductivity; while automotive stamping parts have high requirements for safety performance, the quality control of electrolytic plates is the key, and the highlight of developing structural parts in line with market demand,

The Detail Of BE-CU Metal Stamping Company

Been a China based Metal Stamping Company an important part of our business is short runs and small quantities of customized shapes which include but is not limited to building & construction, transportation, consumer goods, packaging and engineering products.

BE-CU.COM is a China based manufacturer offering Metal Forming services. Our plant specializes in Stamped Metal parts, post machining services and plating or painting. We press a comprehensive range of standard and complex custom shapes and some very challenging designs. With number of processes under one roof we manufacture all sort of products and offer assembly services.Your part drawings will be reviewed in house by be-cu engineers. The press will be designed around the profile according to the intended use for the metal part. Some design considerations, such as wall thickness, tolerances ant type of the metal may need to be taken into account. Off-tool samples will be provided to you after drawings are approved and tool been made.Our team of assemblers specialize in mechanical and electrical assembly of components. We are experienced with a large variety of assembly from simple one or two part additions to complete complex cabinets and assemblies. Additional services also include but not limited to Powdercoating, Plating, E-Coating, General Engineering and custom packaging.
